Product Details:
Payment & Shipping Terms:
|
| Product Name: | Aluminum Oxide | Chemical Formula: | Al2O3 |
|---|---|---|---|
| Orientation: | <11-20><1-102><10-10><0001> | Polish: | Single Side Or Double Sides Polished |
| Size: | 10 X 10 X 0.5 Mm | Density: | 3.97 G/cm3 |
| Hardness: | 9 Mohs | Lattice Parameters: | A = 4.758 Å C =12.99 Å |
| Thermal Expansion Coefficient (/ ℃): | 7.5 × 10^-6 | ||
| High Light: | Aluminum Oxide Al2O3 Substrate,3.97 g/cm3 Al2O3 Substrate,3.97 g/cm3 Aluminum Oxide Substrate |
||
Introduction:
Al2O3(Aluminum Oxide) is an excellent superconducting thin film substrate. This material has many advantages: good thermos-stability,
high thermal conductivity, and high hardness. It also could be used in many other fields like industrial, defense and security and scientific research.
| Crystal Structure | M6 | Melting Point | 2040℃ |
| Density | 3.98 g/cm3 | Polishing | Single side/double side polished |
| Hardness | 9.0 (Mohs) | Redirection the edge | 2°(special in 1°) |
| Lattice Parameters | a = 4.758 Å c =12.99 Å | Ra | ≤5Å(5µm×5µm) |
| Orientation |
A-plane <11-20> M-plane <10-10> R-plane <1-102> C-plane <0001> |
Size |
5*5*0.5mm 10*10*0.5mm |
