superconducting films Magnesium Oxide MgO Single Crystal Substrate

superconducting films Magnesium Oxide MgO Single Crystal Substrate
superconducting films Magnesium Oxide MgO Single Crystal Substrate superconducting films Magnesium Oxide MgO Single Crystal Substrate superconducting films Magnesium Oxide MgO Single Crystal Substrate

Large Image :  superconducting films Magnesium Oxide MgO Single Crystal Substrate

Product Details:
Place of Origin: China
Brand Name: Crystro
Certification: SGS
Model Number: CRMGO-1
Payment & Shipping Terms:
Minimum Order Quantity: 1 Piece
Price: Negotiable
Packaging Details: Transparent clean box
Delivery Time: 3-4 weeks
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 100 pcs per week
Detailed Product Description
Product Name: Magnesium Oxide Chemical Formula: MgO
Crystal Structure: Cubic Lattice Parameters: A = 4.216 Å
Melting Point: 2852 ℃ Density: 3.58 G/cm3
Hardness: 5.5~6 Mohs Thermal Expansion Coefficient (/ ℃): 12.8 × 10^-6
High Light:

MgO Single Crystal Substrate

,

Magnesium Oxide Single Crystal Substrate

,

Magnesium Oxide MgO Substrate



Magnesium Oxide MgO Substrate For High-Temperature Superconducting Films



Introduction:

MgO (Magnesium Oxide) - is widely used as a single crystal substrate for the production of magnetic film, optical film, and high-temperature superconducting films. Because Its dielectric constant and loss microwave band are very small.





Applications:



  • high TC superconductor thin film substrates
  • Ferromagnetic thin films substrates
  • Photo-electronic substrates





Technical parameters:



  Crystal Structure  Cubic  Dielectric Constants  9.80
 Density  3.58 g/cm3  Polishing  Single or double side polished
 Hardness  5.5~6 Mohs  Orientation <100><110><111>
 Lattice Parameters  a = 4.216 Å  Size

 10*10*0.5mm, 10*10*1mm

 20*20*0.5mm ,20*20*1mm

 Melting Point  2852 ℃  Customized  Available
