Product Details:
Place of Origin: China
Brand Name: Crystro
Certification: SGS
Model Number: CRLAO-7
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Transparent clean box
Delivery Time: 3-4 weeks
Payment Terms: T/T, Western Union, MoneyGram,paypal
Supply Ability: 100 pcs per week
Detailed Product Description
Item Name: Lanthanum Aluminate Density: 6.52 (g/cm³)
Mohs Hardness: 6-6.5 Melting Point (℃): 2080℃
Thermal Expansion: 9.4x10-6/℃ Permittivity: ε = 21
Growth Method: Czochralski Color: From Brown To Brownish
High Light:

LaAlO3 Crystal Substrate

,

Crystro Crystal Substrate

,

Crystal Substrate For Epitaxial Growth

Crystro Lanthanum Aluminate LaAlO3 Crystal Substrate For Epitaxial Growth



Crystalline LaAlO3 has a relatively high relative dielectric constant of ~25. LAO's crystal structure is a rhombohedral distorted perrovskite with a pseudocubic lattice parameter of 3.787 angstroms at room temperature (although one source claims the lattice parameter is 3.82 ). Polished single crystal LAO surfaces show twin defects visible to the naked eye.



Main Features:

  • good chemical stability
  • Good lattice match most materials with Perovskite structure
  • Low dielectric constant
  • Low microwave loss



Applications:

  • High-Temperature Superconducting, magnetic, and ferroelectric thin films
  • Low loss microwave applications
  • Dielectric resonance applications



Crystro offers:

Size Max Φ 76.2mm (3''inches)
Thickness 0.5mm /1.0 mm
Polishing Single or Double
Crystal Orientation <100> <110> <111>
Redirection precision ±0.5°
Redirection the edge 2°(special in 1°)
Angle of crystalline Special size and orientation are available upon request
Ra ≤5Å(5µm×5µm)
Pack Class100 clean bag,Class 1000 clean bag



Crystro Lanthanum Aluminate LaAlO3 Crystal Substrate For Epitaxial Growth 0
