| Name: | Cerium Doped Lutetium Aluminum Garnet | Density: | 6.73 G/cm3 |
|---|---|---|---|
| Doping Level: | 0.3% | Size: | 5*5*5mm |
| Hardness: | 8.5 | Thermal Conductivity(W/℃cm,25℃): | 0.08 |
| Light Yield (Photons/MeV): | 15000 | Melting Point: | 1970℃ |
| High Light: | Aluminum Garnet Single Crystal,Scintillation Material Ce LUAG Crystal,Single Crystal Cube |
||
Ce: LuAG crystal has high density, good chemical, mechanical properties, and temperature stability, making this crystal an ideal choice of PET scanner, high-energy gamma-ray and charged particle detection, and X-ray, ultraviolet ray high spatial resolution imaging screen, etc.
Application:
Main Advantages :
Main Properties :
| Property | Ce: LuAG |
| Hardness | 8.5 |
| Density | 6.73 g/cm3 |
| Thermal conductivity(W/℃cm,25℃) | 0.08 |
| expanding coefficient(10-6/℃) | 8.8 |
| Refractive index(λ=1.079μm) | 1.84 |
| Emission peak (nm) | 510 |
| Light yield (Photons•Mev-1) | 15000 |
| Decay time(ns) | 80 |
| Energy resolution | <8% |
Crystro offers :
| Orientation Tolerence | <0.5° |
| Thickness/Diameter Tolerance | ±0.05 mm |
| Parallel | 10'' |
| Perpendicular | 5' |
| Surface Quality | 10/5 |
| Clear Aperture | >90% |
| Chamfer | <0.2×45° |
| Maximum dimensions | Max φ 60 mm |
Product detail :
