LuAG Ce Single Crystal Scintillation Material For High Power Laser Lighting

LuAG Ce Single Crystal Scintillation Material For High Power Laser Lighting
LuAG Ce Single Crystal Scintillation Material For High Power Laser Lighting LuAG Ce Single Crystal Scintillation Material For High Power Laser Lighting LuAG Ce Single Crystal Scintillation Material For High Power Laser Lighting

Large Image :  LuAG Ce Single Crystal Scintillation Material For High Power Laser Lighting

Product Details:
Place of Origin: China
Brand Name: Crystro
Certification: ISO9001
Model Number: CRLUAG-2
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Transparent clean box
Delivery Time: 3-4 weeks
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 100 pcs per week
Detailed Product Description
Name: Ce:LuAG Chemical Formula: Ce: Lu3Al5O12
Density: 6.73 G/cm3 Hardness: 8.5
Melting: 1970℃ Symmetry: Cubic
Cell Parameters(Å): 11.914 Thermal Conductivity(W/℃cm,25℃): 0.08
Expanding Coefficient(10-6/℃): 8.8 Refractive Index(λ=1.079μm): 1.84
High Light:

LuAG Ce Single Crystal

,

Single Crystal Scintillation Material

,

LuAG Ce Scintillation Material




High Light Yield Scintillation Materials LuAG: Ce Crystal For High-Power Laser Lighting



Introduction:



Ce: LuAG crystal is a kind of high-density fast scintillation material. It is also an ideal material for medical scanning systems (Computed tomography, Positron emission computed tomography,) high-energy particle detectors, and laser lighting. Ce: LUAG also has a high density (6.73g/cm3) and fast decay (80ns), which is suitable for thin imaging screens.





Applications:

  • High-performance solid laser
  • White light-emitting diodes (WLEDs)
  • High-power laser lighting
  • High-resolution X-ray imaging
  • PET scanners





Material Properties :

Property Ce: LuAG
Melting (℃) 1970
Cell Parameters(A) 11.914
Hardness(Mohs) 8.5
Density(g/cm3) 6.73
Thermal conductivity(W/℃cm,25℃) 0.08
expanding coefficient(10-6/℃) 8.8
Refractive index(λ=1.079μm) 1.84
Emission peak (nm) 510
Light yield (Photons•Mev-1) 15000
Decay time(ns) 80
Energy resolution <8%



Crystro offers :


Orientation Tolerence <0.5°
Thickness/Diameter Tolerance ±0.05 mm
Parallel 10''
Perpendicular 5'
Surface Quality 10/5
Clear Aperture >90%
Chamfer <0.2×45°
Maximum dimensions dia 60 mm
