Product Details:
Payment & Shipping Terms:
|
| Chemical Formula: | LiNbO3 | Growth Method: | Czochralski |
|---|---|---|---|
| Crystal Structure: | Trigonal System | Dimensions: | 15*4*1.2mm |
| Melting Point: | 1250℃ | Density: | 4.64 G/cm3 |
| Mohs Hardness: | 5 | Refractive Index: | No=2.286 Ne=2.203 (632.8nm) |
| Lattice Constant: | A=b=5.148Å , C=13.863 Å | ||
| High Light: | Optical Lithium Niobate Crystal,Optical Grade LiNbO3 Crystal,High Extinction Ratio LiNbO3 Crystal |
||
Lithium niobate crystal has a long history and the most complete physical effects. It is used to prepare acoustic filters, resonators, delay lines, electro-optic modulators, electro-optic Q-switches, phase modulators, and other devices. It is widely used in electronic technology, optical communication technology, laser technology, and other fields have been widely used, and has shown important application prospects in the recent rapid development of fifth-generation wireless communication technology, micro-nano photonics, integrated photonics, and quantum optics.
High Damage Threshold Threshold
Specifications:
| Growth method | Czochralski |
| Crystal structure | Trigonal system |
| Transparency Range | 420-5200nm |
| Lattice constant | a=b=5.148Å c=13.863 Å |
| Melting point | 1250℃ |
| Curie temperature | 1142 ℃ |
| Density | 4.64 g/cm3 |
| Hardness | 5 Mohs |
| Refractive index | No=2.286 ne=2.203 (632.8nm) |
LiNbO3 Q-switch Specifications:
| Size | available upon request |
| Tolerance of Size | Z-axis: ± 0.2mm |
| X-axis and Y-axis: ± 0.1mm | |
| Chamfer | less than 0.5 mm at |
| Accuracy of Orientation | Z-axis: ＜ ±5′, X-axis and Y-axis: ＜ ±10′ |
| Parallelism | ＜20′′ |
| Finish | 10/5 scratch/dig |
| Flatness | λ/8 at 633nm |
| AR-Coating | R＜0.2% @1064nm |
| Electrodes | Gold/Chrome plated on X-faces |
| Wavefront Distortion | ＜λ/4 @633nm |
| Extinction Ratio | ＞400:1 @633nm, φ 6mm beam |
