Product Details:
Payment & Shipping Terms:
|
| Chemical Formula: | LiNbO3 | Growth Method: | Czochralski |
|---|---|---|---|
| Crystal Structure: | Trigonal System | Melting Point: | 1250℃ |
| Density: | 4.64 G/cm3 | Mohs Hardness: | 5 |
| Refractive Index: | No=2.286 Ne=2.203 (632.8nm) | Lattice Constant: | A=b=5.148Å , C=13.863 Å |
| Diameter: | 6 Inches | ||
| High Light: | 6 Inches Lithium Niobate Crystal,SAW Devices Lithium Niobate Crystal,6 Inches Single Crystal |
||
Lithium oxide crystals have two features that are particularly interesting: first, lithium niobate crystals have many photoelectric effects, and second, lithium niobate crystals have strong performance controllability.
Optoelectronic devices such as surface acoustic wave filters, optical modulators, phase modulators, optical isolators, electro-optical Q-switches, etc. based on lithium niobate crystals have been widely researched and developed in the fields of electronic technology, optical communication technology, and laser technology. practical application.
Recently, with the breakthrough progress in the application fields of fifth-generation wireless communication (5G), micro-nano photonics, integrated photonics, and quantum optics, lithium niobate crystals have once again attracted widespread attention.
Specifications:
| Growth method | Czochralski |
| Crystal structure | Trigonal system |
| Transparency Range | 420-5200nm |
| Lattice constant | a=b=5.148Å c=13.863 Å |
| Melting point | 1250℃ |
| Curie temperature | 1142 ℃ |
| Density | 4.64 g/cm3 |
| Hardness | 5 Mohs |
| Refractive index | No=2.286 ne=2.203 (632.8nm) |
